JNP-SFP-10G-BX60D – 60km BiDi SFP+ Transceiver 10GBASE-BX-D

The JNP-SFP-10G-BX60D is a high-performance 10GBASE-BX-D BiDi SFP+ transceiver designed for cost-effective long-reach 10G Ethernet connectivity.

It supports 10 Gbps data transmission over single-mode fiber (SMF) using a single LC simplex connector, enabling a maximum link distance of up to 60 km.

Operating on paired wavelengths 1330nm (TX) and 1270nm (RX), this BiDi module allows full-duplex communication over just one fiber strand, reducing fiber usage and lowering deployment costs.

The transceiver is fully compliant with SFP+ MSA, SFF-8431/8432/8472, and IEEE 802.3ae standards, ensuring seamless compatibility with a wide range of network equipment, including switches and routers.

The JNP-SFP-10G-BX60D is widely used in data centers, metro networks, enterprise distribution layers, and long-distance interconnect applications.

Key Features

1. 10GBASE-BX-D BiDi SFP+ transceiver​​
2. Supports 10.3125 Gbps data rate (up to 11.3 Gbps)
3. 60 km transmission over single-mode fiber (SMF)
4. Single LC simplex optical interface
5. 1330nm TX / 1270nm RX wavelength pair
6. Hot-pluggable SFP+ footprint
7. Supports Digital Diagnostics Monitoring (DDM/DOM)
8. – real-time monitoring of temperature, voltage, TX/RX optical power
9. Low power consumption (< 1.5W)
10. Compliant with SFP+ MSA, SFF-8431, SFF-8432, SFF-8472
11. Compatible with major OEM switches and routers (Juniper, etc.)
12. Ideal for long-haul 10G Ethernet links up to 60 km

Specifications of JNP-SFP-10G-BX60D – 60km SFP+ BiDi Transceiver

Optical Specifications

Electrical & Physical Specifications

Compatibility

This transceiver is designed for full compatibility with Juniper platforms and is suitable for use in devices such as:

• Juniper EX Series switches
• Juniper QFX Series switches
• Juniper MX routers
• Media converters supporting 10GBASE-BX
• Any SFP+ MSA-compliant port
